Addressable NeoPixel WS2811 WS2812B Digital RGB Led Strip Light

144led/m ws2812b addressable neopixel led strip

Model No.  GE144RGB2812BA (non-waterproof)
           GE144RGB2812BB (IP65 waterproof)
 Working Voltage: DC5V
 Led QTY:  144leds/M
 Led Type: SMD5050
 IC Type:   WS2811 (Built-in LED)
 Dimension: 1000mm*12.0mm*4mm (waterproof)
            1000mm*12.0mm*2.5mm(non-waterproof)
 Pixel QTY: 144pixels/m ,each led addressable
 PCB Color: White or Black
 Power Consumption: Max 43.2W/M
 Brightness Level: 256 level
 Emitting Color: RGB
 Waterproof IP grade:silicon tube IP67/ non-waterproof

96pixel/m ws2812b neopixel led strip
Model No.  GE96RGB2812BA (non-waterproof)
           GE96RGB2812BC(IP67 waterproof)
 Working Voltage: DC5V
 Led QTY:  96leds/M
 Led Type: SMD5050
 IC Type:   WS2811 (Built-in LED)
 Dimension: 2000mm*14.0mm*4mm (waterproof)
            2000mm*12.0mm*2.5mm(non-waterproof)
 Pixel QTY: 96pixels/m ,each led addressable
 PCB Color: White
 Power Consumption: Max 28.8W/M
 Brightness Level: 256 level
 Emitting Color: RGB
 Waterproof IP grade:silicon tube IP67/ non-waterproof

1M 74Pixel WS2812B Addressable Led Strip
Model No.  GE74RGB2812BA (non-waterproof)
           GE74RGB2812BC(IP67 waterproof)
 Working Voltage: DC5V
 Led QTY:  74leds/M
 Led Type: SMD5050
 IC Type:   WS2812B (compatible with ws2811)
 Dimension: 5000mm*14.0mm*4mm (waterproof)
            5000mm*12.0mm*2.5mm(non-waterproof)
 Pixel QTY: 74pixels/m ,each led addressable
 PCB Color: White or Black color
 Power Consumption: Max 22.2W/M
 Brightness Level: 256 level
 Emitting Color: RGB color
 Waterproof IP grade:silicon tube IP67/ non-waterproof

5V 72LED/M WS2811 NeoPixel Led Strip
Model No.  GE72RGB2811A (non-waterproof)
           GE72RGB2811C(IP67 waterproof)
Working Voltage: DC5V
Led QTY:  72leds/M
Led Type: SMD5050
IC Type:  ws2811
Dimension: 5000mm*14.0mm*4mm (waterproof)
           5000mm*12.0mm*2.5mm(non-waterproof)
Pixel QTY: 72pixels/m ,each led addressable
PCB Color: White or Black color
Power Consumption: Max 21.6W/M
Brightness Level: 256 level
Emitting Color: RGB
Waterproof IP grade:silicon tube IP67/ non-waterproof

68led ws2811 strip
Model No.  GE68RGB2811A (non-waterproof)
           GE68RGB2811C(IP67 waterproof)
Working Voltage: DC5V
Led QTY:  68leds/M
Led Type: SMD5050
IC Type:   WS2811 (Built-in LED)
Dimension: 5000mm*14.0mm*4mm (waterproof)
           5000mm*12.0mm*2.5mm(non-waterproof)
Pixel QTY: 68pixels/m ,each led addressable
PCB Color: White or Black color
Power Consumption: Max 20.4W/M
Brightness Level: 256 level
Emitting Color: RGB/W/R/G/B/other single color
Waterproof IP grade:silicon tube IP67/ non-waterproof

60led/m ws2811 ws2812b addressable strip
Model No.  GE60RGB2811A (non-waterproof)
           GE60RGB2811C(IP67 waterproof)
 Working Voltage: DC5V
 Led QTY:  60leds/M
 Led Type: SMD5050
 IC Type:   WS2811 (Built-in LED)
 Dimension: 5000mm*12.0mm*4mm (waterproof)
            5000mm*10.0mm*2.5mm(non-waterproof)
 Pixel QTY: 60pixels/m ,each led addressable
 PCB Color: White or Black color
 Power Consumption: Max 18.0W/M
 Brightness Level: 256 level
 Emitting Color: RGB/W/R/G/B/other single color
 Waterproof IP grade:silicon tube IP67/ non-waterproof

32LED WS2811 RGB Strip
Model No.  GE32RGB2811A (non-waterproof)
           GE32RGB2811C(IP67 waterproof)
Working Voltage: DC5V
Led QTY:  32leds/M
Led Type: SMD5050
IC Type:   WS2811 (Built-in LED)
Dimension: 5000mm*14.0mm*4mm (waterproof)
           5000mm*12.0mm*2.5mm(non-waterproof)
Pixel QTY: 32pixels/m ,each led addressable
PCB Color: White or Black color
Power Consumption: Max 9.6W/M
Brightness Level: 256 level
Emitting Color: RGB/W/R/G/B/other single color
Waterproof IP grade:silicon tube IP67/ non-waterproof

1M 30Pixel WS2812B NeoPixel Led Strip
Model No.  GE30RGB2812BA (non-waterproof)
           GE30RGB2812BB (IP65 waterpprof)
           GE30RGB2812BC(IP67 waterproof)
           GE30RGB2812BD(IP68 waterproof)
 Working Voltage: DC5V
 Led QTY:  30leds/M
 Led Type: SMD5050
 IC Type:   WS2811 (Built-in LED)
 Dimension: 5000mm*10.0mm*2.5mm (non-waterproof)
            5000mm*10.0mm*3.5mm(IP65-waterproof)
            5000mm*12.0mm*4.0mm (IP67-waterproof)
            5000mm*12.0mm*4.0mm(IP68-waterproof)
 Pixel QTY: 30pixels/m ,each led addressable
 PCB Color: White or Black color
 Power Consumption: Max 9W/M
 Brightness Level: 256 level
 Emitting Color: RGB color

6PIN FEET WS2811 Chip Embedded In 5050 RGB LED
Dimensions: 5mm x 5mm x 1.6mm
Voltage: 5.0V
Current 20ma per color, 60mA total at full brigtness
Viewing angle: 120 degres.
Luminous intensity at 5V: R=550-700mcd G=1000-1200mcd B=300-400mcd.

4Pin Feet WS2812B Chip Built In SMD5050 RGB LED
Dimensions: 5mm x 5mm x 1.6mm
Voltage: 5.0V
Current 20ma per color, 60mA total at full brigtness
Viewing angle: 120 degree.
Compatible with ws2811 library.

WS2811 IC Chip Driver

 1. Output port pressure 12 V.

 2. Built-chip regulator, 24V only series resistance of the following power supply terminal to the IC the VDD pin, no external regulator.Grayscale adjustment circuit (256-color adjustable).

 3. Built-in signal shaping circuit, after any one IC signal is received.

 4. A variety of other LED lighting products.

 5. Waveform shaping output, to ensure that the line waveform distortion may not add up.

 6. Built-in power-on reset and brown-out reset circuit.

 7. PWM control side can achieve 256 adjustment, scanning frequency of 2.5KHz.

 8. Serial Interface cascade interface, through a signal line to complete the data reception and decoding.

 9. Any two pass transmission distance over 20 m without increasing any circuit.

 10. Data transmission speed up to 400Kbps and 800Kbps two modulus
